The IDS-F600S is a newly designed 21.5-inch LCD industrial touchscreen dispatcher featuring durability, shock resistance, moisture protection, dust prevention, high-temperature tolerance, multiple slots, and easy expandability. It is suitable for enterprises and institutions in professional dispatch communication fields across industries such as electric power, metallurgy, chemical engineering, petroleum, coal, mining, transportation, and public security.
The installation methods include panel mounting, desktop adjustable viewing angle (65° horizontal adjustment), and embedded VESA standard (65° angle flip) industrial tablets. Constructed with aluminum-magnesium alloy, it is lightweight, aesthetically pleasing, and meets military-grade standards.
Departing from conventional IP phones, it incorporates a 7-inch touchscreen IP phone, enabling three touchscreens for operation on a single dispatcher. This exemplifies the high-tech integration of products, bringing modernized features and maximizing the advantages of new-generation dispatch systems for customers.

Liquid Crystal Display:

• Display area: 405×255mm
• Diagonal display size: 19 inches
• Contrast ratio: 1000:1
• Brightness: 450cd/m²
• Response time: 8ms
• Viewing angle (H/V): 170°/170°
• Display color: 262K
• Pixels (H/V): 1440×900 pixels

Touch Screen:

• Touch type: 4-wire/5-wire resistive touch screen (optional)
• Resolution: 4096*4096 (continuous)
• Operating pressure: 30～45 grams of force, contact jitter <10ms
• Click life: 10 million times with 250 grams of force
• Light transmittance efficiency: >81%

Environmental Parameters:

• Storage temperature: -20℃～+60℃
• Operating ambient temperature: 0℃～+50℃
• Humidity: 5%—95% non-condensing

21.5-inch high-brightness LCD screen with a 7-inch touchscreen IP phone
Integrated industrial-grade low-power embedded motherboard, supporting CF and HDD, with multiple I/O interfaces; resistive touchscreen, 19-inch LCD screen, adjustable brightness and contrast, and standby energy-saving mode.

Product Features: Structural Parameters
Front Panel: Industrial gray sheet metal material, with oxidation and spray coating treatment
Cabinet Structure: Surface oxidation treatment, featuring an attractive appearance, light weight and good heat dissipation performance
Overall Dimensions: 830mm×260mm×235mm
Voltage/Power Consumption: 220V
