Industrial IP Waterproof and Dustproof Public Address Telephone BK-FS1-Bek Industrial Communications

Industrial IP Waterproof and Dustproof Public Address Telephone BK-FS1

BK-FS1

BK-FS1 industrial phone, with composite shell (10mm thick), meets IP66 (GB4028-93). Resists impacts, aging, corrosion, extreme temps. Ideal for harsh environments like tunnels, mines, plants.......

Datasheet instructions

Product Introduction

The BK-FS1 industrial waterproof and dustproof special telephone features an integral shell made of composite new materials, with an overall mold-forming structure and a concise and elegant design. Its 10mm thick and sturdy wall can resist heavy impacts and knocks. The unique material properties offer excellent anti-aging, corrosion resistance, waterproofness, moisture resistance, high and low temperature resistance, flame retardancy, and insulation. The entire device meets the IP66 requirements specified in the national standard GB4028-93, ensuring stable and reliable performance. It is suitable for harsh environments requiring waterproofness, moisture resistance, fire resistance, and noise resistance, such as underground pipe corridors, subway and highway tunnels, metal mines, various power plants, steel mills, ship terminals, oil fields, outdoor jungles, and large production workshops.

Product parameters

Supports SIP standard network protocol.
Compatible with 36-48V program-controlled switches.
Integrates 30W public address speaker and LED flash for audio-visual alerts and broadcast notifications.
Stores multiple preset numbers for auto-dialing.
Auto-power-on upon detecting ringing signals.
Monitors busy tones and auto-hangs up.
Industrial-grade handset with Teflon high-temperature wire and noise-canceling microphone.
Flashing warning light prevents misdialing during incoming calls.
(Duplicate of #7)
Large dual-contact silicone keypad for gloved operation.
Non-metallic magnetic hook switch eliminates spark hazards.
Intercom button enables broadcast communication.
Composite material housing resists impact and vandalism.
IP66-rated waterproof, dustproof, moisture-resistant, and frost-proof.
Various 外形 and color options available.
Integrated flash design simplifies installation compared to traditional separate speaker/light systems.
Magnetic door cover allows quick access.

Featured Features

Supports SIP V1 (RFC2543) and V2 (RFC3261) protocols.
One-key IP announcement: Press and hold the hands-free key for ~10 seconds to auto-announce IP; alternatively, lift the handset and dial **9114.
Provides 5 SIP account registrations with automatic failover to ensure continuous communication.
Features two emergency buttons:
Answer calls: Lift the handset to answer incoming calls.
Make calls: Press the emergency button to dial a pre-set hotline (configured via WEB interface).
Activate broadcast: Upon unanswered incoming calls, the device auto-answers after a timeout, broadcasting the caller’s voice.
Auto-hangup: Automatically terminates calls to avoid blocking incoming calls.
Works with SIP PBX for group calling, call pickup, and recording.
