How to Properly Install and Configure VOS3000 System (Basic Functions and Future Trends)

1. What is VOS3000?

VOS3000 is a VoIP operation support system with a powerful set of functions and reliable security guarantees. It can support up to 5000 concurrent calls. It is applicable to various business scenarios such as call forwarding, enterprise terminals, APP services, and dispatching in large call centers.

2. Basic Functions of VOS3000

The VOS3000 system provides functions including but not limited to the following:

• Rate Management: It supports international standard SIP and H.323 protocols as well as protocol conversion between them. It also provides rate management, account management, package management, phone management, gateway management, registration management, IMS docking, number management, and system management, etc.

• Dual-Machine Hot Backup: It supports the dual-machine hot backup solution to ensure that there is no single point of failure in the system and realizes real-time hot backup in the master-slave mode.

• Service Security: It provides security safeguard measures such as SSH security reinforcement, MYSQL security reinforcement, Linux operating system security reinforcement, and a complete password authentication mechanism.

• Real-Time Alarm Monitoring: It provides a complete alarm mechanism, including real-time monitoring of hardware status, service conditions, and operational data such as ASR and ACD.

• Account Anti-Overdraft: It supports setting the number of minutes in advance, ensuring from the algorithm level that the system will never be overdrawn, thus better protecting the vital interests of operators.

3. Installation and Configuration of VOS3000

1. Installation Steps

1. Hardware Preparation: Ensure that the server has sufficient processing power, storage capacity, and network bandwidth to support the expected telephone load.
2. Operating System Installation: Select a suitable operating system, such as CentOS 6 - 7, and install it. Follow the installation wizard of the operating system to operate and choose a suitable partitioning scheme and disk format.
3. Software Installation:
   • Upload the VOS3000 installation package to the server and decompress it.
   • Execute the installation process according to the VOS3000 installation documentation or guide. This may involve installing necessary dependent libraries and components.
4. Database Configuration:
   • VOS3000 relies on a database to store related configurations and information. Firstly, it is necessary to install database software, such as MySQL or MariaDB.
   • Create a database instance and set relevant database connection parameters.
5. Configure Network: Configure the network settings of the server to ensure that the server has Internet connection and necessary ports are open. This may involve setting a static IP address, subnet mask, gateway, and DNS, etc.
6. System Configuration: Configure various parameters of VOS3000 according to actual needs and business scale. This includes setting the system time, time zone, language, license, and security settings, etc. It is also necessary to set relevant communication devices, such as PRI lines or VoIP gateways.
7. Port and Routing Configuration: Configure the telephone ports and routing rules of VOS3000. This includes creating call routes, setting tariff plans and routing strategies, and configuring internal and external calls, etc.
8. Security Settings: In order to ensure the security of the system, it is necessary to configure firewalls and other security measures to restrict untrusted access and protect the system from potential attacks.
9. Testing and Debugging: After completing the installation and configuration, conduct system testing and debugging. Test call connections, voice quality, and other functions to ensure the normal operation of the system.

2. Configuration Guide

1. Number Communication Configuration and Testing:

   • Creation of Phones: Business Management -> Phone Business -> Phone Management -> Filter, select Add. The phone number and password will be used later. Select the landing gateway, double-click the information of the landing gateway group -> Click... -> Add -> Double-click the default one and then select one (select Apply after setting, otherwise it will not be saved).
   • View Your Own Phones: Business Management -> Phone Business -> Phone Management -> Filter (you can fill in the phone number in the filter).
   • eyeBeam Phone Settings: Display Menu -> SIP Account Settings -> Add. Display Name: Set the phone number for hang-up management by yourself. Username: The phone's own number. Password: The phone management phone number. Authorized User: The phone's own number. Domain Name: The IP address of the number that needs to be tested (the IP address for logging into VOS).
   • Testing Communication:
     • System -> Account Management -> Select Settlement Account for Account Type -> Filter.
     • Double-click to enter the account that needs to be tested, and double-click the number of network managers to enter.
     • Click Edit -> Landing Prefix, copy the main calling prefix of the landing (if there are multiple ones, just copy one).
     • Fill in the copied number into the outgoing call display of phone management, and copy the network manager group to the network manager group of the phone.
     • Add SIP to the eyeBeam phone and then you can make calls.

2. Configuration Steps for Building the VOS3000 Internet Telephone System:

   • Obtain VOS3000 Software: Obtain the VOS3000 software installation package through formal channels. VOS3000 is commercial software and requires purchasing an authorization.
   • Prepare the Server: Prepare a dedicated server. The operating system usually recommends choosing Linux, such as CentOS or Ubuntu versions, etc. Ensure that the server has sufficient hardware resources, such as CPU, memory, and storage space.
   • Install the Operating System: Install the selected Linux operating system on the server and conduct basic system configuration and security settings.
   • Install VOS3000 Software: Run the VOS3000 software installation package and follow the installation wizard to install it. You need to provide the authorization key obtained when purchasing the software.
   • Configure Network and Ports: Configure the network settings and ports on the server to ensure that the server can communicate with the external network and open the required ports, such as the SIP port (usually 5060), the management port (such as 8888), etc.
   • Conduct System Settings: Run the management interface of VOS3000, which can usually be accessed in a Web browser. When logging in for the first time, you need to modify the default password and conduct necessary system settings, such as time zone, domain name, etc.
   • Create Users and Routes: According to business requirements, create user accounts and set call routes and billing strategies, which will determine how users make calls and the charging standards, etc.
   • Security Settings: In order to protect system security, some security measures can be taken, such as restricting access to the management interface, configuring firewalls, and enabling logging, etc.
   • Testing and Optimization: After completing the above settings, conduct system testing and optimization to verify that users can make and receive calls normally and check whether the system runs stably.
   • Provide Technical Support: Once the system is built, technical support can be provided to users to ensure that there is sufficient knowledge and experience to handle users' problems and troubleshoot.

3. Configure Ignore Prefix for Non-Standard 11-Digit Mobile Phone Numbers (Taking the VOS3000 Outbound Call System as an Example):

   • Log in to the VOS3000 Management Interface: Log in using the administrator account.

   • Set Ignore Prefix:

     • Softswitch Management Settings: After logging in, find the Supplementary Settings option in the softswitch management, enter the system parameter configuration interface, find the system parameter named SS_NON_STANDARD_PREFIX, and fill in a specific value in this parameter, for example, 999. In this way, when the system encounters a non-standard mobile phone number starting with 999, it will automatically ignore this prefix and then recognize and process the subsequent numbers.

     • Business Configuration: Enter the business configuration interface, find the Domestic Business Rule Settings option, and set parameters such as number length and number prefix in this option to ensure that the system can correctly recognize non-standard 11-digit mobile phone numbers. Also set the ignore prefix in the domestic business rules to cooperate with the previous softswitch management settings.

   • Set Black and White Lists: When adding black and white list rules, also set the ignore prefix so that when the system checks whether the phone number is in the black and white lists, it will automatically ignore the prefix of non-standard mobile phone numbers, thus ensuring the accuracy of the black and white list functions.

   • Save Settings and Test Verification: After completing the above configurations, save the settings and ensure that the modifications take effect, and then conduct test verification.

4. VOS3000 Client Incoming Call Configuration (Taking Super Simple Five Steps as an Example):

   • View SIP Proxy: In the registration management, view the SIP proxy IP address registered by your line, and record it.
   • Create a Normal Account: Create a normal account for incoming calls, select "Billing Rate", and choose the rate according to your own situation. For testing here, a free rate is configured. If the rate is not free, you need to recharge this normal account.
   • Newly Build a Docking Gateway: Newly build a docking gateway, click the "Supplementary Settings" of this gateway, select "Gateway Type" as static IP, and then fill in the SIP proxy IP address recorded in the registration management in the IP address field.

4. What Protocol Types of Calls Does the VOS3000 System Support?

The VOS3000 system supports calls of multiple protocol types, including but not limited to the following:

The support for these protocols enables the VOS3000 system to interconnect with different devices and networks, realizing comprehensive interoperability and meeting diverse communication needs. It is especially suitable for multinational enterprises and scenarios that require network construction across different operators.

5. Methods for the VOS3000 System to Ensure Call Quality and Stability

The VOS3000 system ensures call quality and stability through a series of technical means and management strategies. The following are some key points:

• Solving Transmission and Routing Problems: For the VOS system, transmission and routing are crucial components. The system will give priority to solving transmission failures, routing problems, or quality issues to ensure smooth and stable calls. This includes preventing network attacks, vulnerabilities, and authentication defects, as well as monitoring the processing capabilities of the transmission network and the devices it passes through.

• Adjusting System Scale and Capacity: As the number of users increases or business needs change, the system may need to expand its scale and capacity. This involves increasing resources such as servers, bandwidth, and storage space to meet user needs and maintain system performance.

• Function Improvement and Update: With the development of business, the system may need to add new functions or improve existing ones. This includes function improvements that have a significant impact on user experience and business growth, as well as continuous optimization of system performance and stability.

• Customer Support and User Experience Optimization: Ensuring timely response and support to users is also very important. Handling users' problems and feedback, improving user experience, and providing high-quality customer support should be prioritized.

• Flexible Billing Strategy: VOS3000 adopts a flexible billing strategy, such as regularly replacing rates, automatically generating customer rates, recalculating CDR according to rates, and having rich package forms, providing comprehensive and efficient support for operators to formulate sales strategies and marketing plans.

• Rich Business Expansion: VOS3000 supports rich business expansion. Corresponding IVR modules, voice encoding conversion modules, and recording sampling modules can be optionally configured to achieve corresponding business functions.

• Detailed Report Output: It supports the output of various reports, such as income detail reports, gateway call charge reports, phone call charge reports, account region reports, account income and expenditure reports, agent income reports, settlement account detail reports, settlement account region reports, settlement gateway detail reports, account settlement income and expenditure reports, and settlement financial summary reports, etc. This helps users to understand call situations in real time and conduct business analysis and optimization.

Through the above measures, the VOS3000 system can effectively ensure call quality and stability and meet the needs of enterprises and operators of different scales.

6. Security Protection Measures of the VOS30

As a professional softswitch system, the VOS3000 system is mainly used for small and medium-sized VoIP operation services. Its security protection measures are crucial for ensuring the normal operation of the system and the security of user data. The following are some specific security protection measures:

• Use Firewalls: Installing and configuring firewalls is the first line of defense for protecting the VOS3000. It can prevent scans and attacks on the response ports of the VOS3000 system, control the access rights of inbound and outbound traffic, and restrict traffic to only pass through predefined ports and protocols.

• Encrypt Connections: Use the TLS protocol to encrypt the connections of the remote management interface, web management, and telephone lines provided by the VOS3000 to prevent password leakage and information leakage.

• Update the System and Programs: Keep the VOS3000 and its components updated to the latest version to prevent the exploitation of known attack vulnerabilities. Meanwhile, use antivirus software and vulnerability scanners to ensure that there are no security vulnerabilities in the system software and application programs.

• Strengthen Password Policies: Strengthen the password policies for VOS3000 user accounts. For example, set complexity rules such as minimum length, special characters, numbers, and uppercase and lowercase letters to ensure that passwords are strong enough. Regularly changing passwords is also a recommended security practice.

• Restrict Interface Access: The remote management interface of the VOS3000 is a very important part and should be restricted to specific IP addresses. Clearly limit the source IP addresses that can access the management interface to prevent unauthorized users from accessing the VOS3000 management interface.

• Monitor Logs: Regularly check the system and application program logs of the VOS3000 to look for security events and abnormal behaviors in the system. This helps to discover potential risks and take timely measures to prevent further losses.

• Isolate Important Services: Isolate important services on independent servers to facilitate security isolation and restrict access to important services. Ensure that only authorized administrators can perform relevant operations.

• Improve System Throughput: Formulate load balancing strategies to filter malicious requests and improve system throughput to deal with attacks.

• Cooperate with Hosting Providers: Contact the VPS provider, inform them that your server is under a DDoS attack, and seek their help and support.

These measures jointly form the security protection system of the VOS3000 system, aiming to prevent unauthorized access or attacks and protect the stable operation of the system and the security of user data.

7. Development Trends of VOS3000

As an advanced VoIP softswitch platform, the VOS3000 will show the following trends in its future development:

• Deep Integration with Call Center Systems: The VOS3000 will continue to strengthen its integration with call center systems and provide more efficient communication access and management functions. This will help enterprises improve the quality of customer service and reduce operating costs.

• Sound Quality Optimization: With the development of technology, the VOS3000 will continuously optimize the sound quality of its outbound call system. This includes measures in multiple aspects such as network configuration optimization, audio codec adjustment, hardware and server inspection, and software updates.

• Function Expansion: The VOS3000 will support more business expansion functions, such as dual-machine hot backup, voice sampling, recording, and transcoding. These functions will further improve the reliability and flexibility of the system.

• Flexibility of Billing Strategies: The VOS3000 will continue to provide flexible billing strategies, including real-time billing, forced disconnection, and precise matching according to number prefixes. This will provide comprehensive support for operators to formulate sales strategies and marketing plans.

• Enhancement of Report Functions: The VOS3000 will provide more detailed report outputs, including call charge reports, settlement reports, and analysis reports. These reports will help enterprises better monitor operational data and make wiser decisions.

• Security Enhancement: The VOS3000 will adopt more advanced security encryption technologies, such as SHA512 and RSA2048 encryption, to ensure the security of the system and data protection.

• Support for Cross-Operator Network Construction: The VOS3000 will continue to support cross-operator network construction, solve the interconnection problems across multiple operator networks, and ensure that users can obtain the best quality calls when accessing any network.

• Intelligent Cockpit Applications: With the development of intelligent cockpit technology, the VOS3000 may be more widely used in the field of intelligent cockpits to achieve functions such as multi-sound zone positioning and recognition.

• Combination with Artificial Intelligence: The VOS3000 may be combined with artificial intelligence technologies, such as integrating XiLing digital humans, to further improve the customer service experience.

• Expansion in the International Market: The VOS3000 will continue to expand in the international market, support multiple international standard protocols, such as SIP and H.323, to meet the communication needs of multinational enterprises.

These trends indicate that the VOS3000 will continue to maintain its leading position in the VoIP field, continuously improve the performance, functions, and security of the system to meet the growing communication needs of enterprises and telecom operators.
